HTU sensor (access door interlock) removal
1. Remove all output options from the printer.
2. Remove the front redrive cover. See “HTU front redrive cover removal” on page 4-293.
3. Press the outer tabs (A) to remove the sensor cover.
4. Press the inner tabs (B) to pull out the sensor.
5. Disconnect the cable to remove the sensor.
A
B
