3-18 Service Manual
5062
OUTPUT BIN TESTS
Feed Test
Note: If the “Configure Bins” printer setting is link rather than mailbox, the printer selects its own internal bin
linking regardless of which output bin is selected for the feed test.
This test verifies that media can be fed to a specific output bin. No information is printed on the media because
the printhead is not turned on during this test.
To run the Output Bin Feed Test:
1. From the Diagnostics menu, navigate to:
OUTPUT BIN TESTS > Feed Test
2. Select the output bin you want the paper to exit into. All installed output bins appear.
3. Select either Single (one sheet of media feeds to the selected output bin) or Continuous (media
continues feeding to the selected output bin) until Stop (
X) is pressed.
4. Press Stop (X) to exit the test.
Feed to All Bins
One page is fed to every bin, including the finisher, if available. The test runs continuously until Stop (X) is
pressed.
Sensor Test
This test verifies that the output bin sensors are working correctly.
To run the Output Bin Sensor Test:
1. From the Diagnostics menu, navigate to:
OUTPUT BIN TESTS > Sensor Test
2. Select the bin you want to test.
Not all sensors appear for each output bin. The following table indicates which tray sensors are available
for each output bin:
Sensor
Standard
output bin
Horizontal
Transport Unit
(HTU)
High Capacity
Output
Stacker
5-bin Mailbox
Bin Empty
1
Bin Near Full
sensor
2
Bin Full
3
PassThru 1
sensor
4
3
PassThru 2
sensor
4
Cover
5
Option Dock
6
Chad Bin Present
7
Chad Bin Full
3
