Lexmark C792 series - ITU Assembly Removal

Repair information 4-77
5062
Go Back
Previous
Next
ITU assembly removal
See “Left (continued)” on page 7-13 for the part number.
1. Remove the waste toner container. See “Waste toner container removal” on page 4-158.
2. Remove the print cartridges.
3. Open the left access door assembly all the way.
4. Grasp the ITU handle (A), and carefully slide the ITU assembly from the printer.
Warning: Be careful to support the ITU as you remove it to avoid damaging the components on the left
access door.
A
