Lexmark C792 series - Bin-Full Flag Removal

To Next Page

To Previous Page

Repair information 4-37

5062

Go Back

Bin-full flag removal

See “Top, right, and front covers” on page 7-3 for the part number.

1. Pull the flag forward out of the clips.

2. Rotate the flag, and pull to remove it.
