Lexmark C792 series User Manual

2-14 Service Manual
5062
Go Back
Previous
Next
24x paper jam
Paper jam in Tray 1:
1.
Open the left access door.
2. Grasp the jammed paper on each side, and then gently pull it out.
3. Close the door.
4. From the operator panel, touch Continue, jam cleared.
Paper jam in the optional trays:
1.
Open the side door of the specified optional tray.
2. Grasp the jammed paper on each side, and then gently pull it out.
3. Close the side door.
4. From the operator panel, touch Continue, jam cleared.
232.04 D2 sensor broke early.
Possible causes:
• Damaged D2 sensor
• Faulty fuser
• Faulty system board
The D2 sensor may not be functioning properly. Go
to “D1 and D2 sensor service check” on
page 2-147.
232.05,
232.07
D2 sensor never broke.
Possible causes:
• Damaged D2 sensor
• Faulty fuser
• Faulty system board
1. Check for anything in the paper path that might
cause the paper to jam.
2. If clearing the jam does not solve the problem,
go to “D1 and D2 sensor service check” on
page 2-147.
232.08 D2 sensor is never made. See “232.03” on page 2-13.
Error code Description Action

Lexmark C792 series Specifications

General

Print Technology	Color Laser
Print Speed (Letter, Black)	50 ppm
Print Speed (Letter, Color)	50 ppm
Processor Speed	1.2 GHz
Monthly Duty Cycle	150, 000 pages
Maximum Paper Size	8.5 x 14 inches (Legal)
Operating System Compatibility	Windows, Mac OS, Linux
Print Resolution	1200 x 1200 dpi
Duplex Printing	Standard
Connectivity	USB, Ethernet
Media Sizes Supported	A4, A5, Letter, Legal, Executive, Folio, JIS B5
Media Types Supported	Card Stock, Envelopes, Labels, Plain Paper, Transparencies
Input Capacity (Standard)	650 sheets
Output Capacity (Standard)	500 sheets
