4-336 Service Manual

5062

Go Back

HTU punch unit removal

1. Remove the HTU rear standard bin cover. See “HTU rear standard bin cover removal” on page 4-312.

2. Remove the HTU top right cover See“HTU top right cover removal” on page 4-329.

3. Remove the E-clip (A), and then remove the gear and gear cap.

4. Disconnect the cable (B) from the punch unit.
