Printhead removal, installation, and alignment

See “Top, right, and front covers” on page 7-3 for the part number.

1. Remove the printhead access cover. See “Printhead access cover removal” on page 4-19.

2. Remove the system board shield. See “System board shield removal” on page 4-27.

3. Disconnect the three printhead cables (A) from the system board, and feed the cables through the slot in

the system board shield.
