Repair information 4-223
5062
Go Back
Previous
Next
Installation note:
Make sure that the pick arm lever (A) is on top of the actuator lever (B).
If the pick arm is hanging, press the actuator lever as shown in the picture.
Make sure that the pick arm is positioned as shown in the picture.
A B
