2-100 Service Manual
5062
5
Check the cable in connector JPP2 for any
other damage.
Is the cable damaged?
Replace the paper path
cable. See “Paper path
cables” on page 7-56.
Go to step 6.
6
Remove the staging deflector assembly. See
“Staging deflector assembly removal” on
page 4-140.
Is the cable connected correctly?
Go to step 7. Reseat the cable.
7
Replace the near narrow media sensor. See
“Sensor (input, S1, narrow media, near
narrow media) removal” on page 4-138.
Does the error reoccur?
Replace the system board.
See “System board
removal” on page 4-151.
Problem solved.
Step Questions / actions Yes No
