2-148 Service Manual
5062
3
Check the cable for damage.
Is the cable damaged?
Replace the duplexer
cable.
To access the cable, see
“LVPS exit duct removal”
on page 4-89
and
“Left cover removal” on
page 4-11.
Go step 4.
4
Remove the duplex cable cover.
Check the cable for proper connection.
Is the cable connected correctly?
Go to step 5. Reseat the cable.
Step Questions / actions Yes No
