3-42 Service Manual
5062
Go Back
Previous
Next
b. Swing the shield open about an inch, and then slide the shield to the left to remove it.
4. Carefully unplug the printhead video cables (B) and the printhead motor cable (C) from the system board,
and carefully connect the printhead video and motor cables from the new printhead to the system board.
Note: Use the packaging that came with the printhead FRU to prop up the printhead.
5. Connect the power cord to the outlet and to the printer. Reconnect any cords.
6. Turn on the printer, and check for the error message:
• If the error still appears, replace the system board. See “System board removal” on page 4-151.
• If the error no longer appears, replace the printhead. See “Printhead removal, installation, and
alignment” on page 4-123.
C
B

Lexmark C792 series Specifications

General

Print Technology	Color Laser
Print Speed (Letter, Black)	50 ppm
Print Speed (Letter, Color)	50 ppm
Processor Speed	1.2 GHz
Monthly Duty Cycle	150, 000 pages
Maximum Paper Size	8.5 x 14 inches (Legal)
Operating System Compatibility	Windows, Mac OS, Linux
Print Resolution	1200 x 1200 dpi
Duplex Printing	Standard
Connectivity	USB, Ethernet
Media Sizes Supported	A4, A5, Letter, Legal, Executive, Folio, JIS B5
Media Types Supported	Card Stock, Envelopes, Labels, Plain Paper, Transparencies
Input Capacity (Standard)	650 sheets
Output Capacity (Standard)	500 sheets
