Lexmark C792 series

To Next Page

To Previous Page

Repair information 4-9

5062

Go Back

10. Open the left access door all the way, and disconnect the rear piston by pulling apart the clamps (F) from

the tabs.

11. Remove the E-clip (G) from the front piston.

G (1126829)
