Repair information 4-45
5062
Go Back
Previous
Next
4. From the memory block you are removing, press the lever (E) to access the sensor, push the right side of
the sensor to remove it, and then disconnect the cable from the sensor.
5. Remove the two screws (F), and pull to remove the memory block. As you pull the cable through, be sure
to leave the string in the path from the memory block to the system board.
Installation notes:
1. Attach the memory block and tie the string to its cable.
2. Connect the sensor cable to the sensor, and then attach the sensor to the memory block.
3. From the rear of the printer, pull the string to feed the memory block cable through the frame to the
system board.
Warning: Be sure to pull the cable into the system board cage area as far as possible. Failure to do may
damage the cables.
E
F (88A0212)

Lexmark C792 series Specifications

General

Print Technology	Color Laser
Print Speed (Letter, Black)	50 ppm
Print Speed (Letter, Color)	50 ppm
Processor Speed	1.2 GHz
Monthly Duty Cycle	150, 000 pages
Maximum Paper Size	8.5 x 14 inches (Legal)
Operating System Compatibility	Windows, Mac OS, Linux
Print Resolution	1200 x 1200 dpi
Duplex Printing	Standard
Connectivity	USB, Ethernet
Media Sizes Supported	A4, A5, Letter, Legal, Executive, Folio, JIS B5
Media Types Supported	Card Stock, Envelopes, Labels, Plain Paper, Transparencies
Input Capacity (Standard)	650 sheets
Output Capacity (Standard)	500 sheets
