4. Disconnect the cable (B) from the fuser motor.
5. Remove the three screws (C).
6. Remove the fuser drive assembly.
Installation note: Be sure to apply grease to the gear and post using the instruction sheet and two kinds of
grease that came with the fuser drive assembly.
B
C (88A0212)
