Lexmark C792 series

To Next Page

To Previous Page

Repair information 4-91

5062

Go Back

3. Push in to open the cable clip (B) behind the system board shield.

4. Feed the cable through the slot in the system board cage and the clip.

5. Remove the two screws (C).

C (10B1580)
