Repair information 4-141

5062

Go Back

Installation notes:

• Be sure the cables are routed through the cable hooks (B) before you snap the assembly into place. Use

the cable lengths as a guide to make sure you connect the correct cable to each sensor.

• Be sure the hooks engage both the bottom and top posts on each side.
