Lexmark C792 series

To Next Page

To Previous Page

4-200 Service Manual

5062

Go Back

8. Release the jam clearance cover cable from the cable guides (B).

9. Remove the screw (C) and press the latch (D) to release the jam clearance cover sensor.

D C (88A0312)
