Lexmark C792 series

To Next Page

To Previous Page

5-12 Service Manual

5062

Go Back

550-sheet tray option system card

connectors

See “550-sheet tray option system card” on page 5-11.

Connector Pin # Signal Pin # Signal

Jam door sensor

1GND

2 Input

3 +5V_Switch

Pick motor

1 +5V_Switch

2 ENCODER

3GND

4 Motor +

5 Motor -

Paper level sensor

1 +5V_Switch

2 P_LEV_SENSOR_1

3GND

5 +5V_Switch

6 P_LEV_SENSOR_2

7GND

J10

Feed motor

1 +5V_Switch

2 ENCODER

3GND

4 Motor +

5 Motor -

J17

Jam Led

1 JAM_LIGHTPIPE

2 Ground

3 JAM_DOOR_LED

4 Ground

J30

Paper port to next option

1GND

2 PP_RXD

3GND

4 PP_TXD

5 MTR2 ENCODER

6S2

J32

Paper port to printer

1GND

2 PP_RXD

3GND

4 PP_TXD

5S2
