Lexmark C792 series

To Next Page

To Previous Page

Connector locations 5-19

5062

Go Back

5-bin mailbox system card

5-bin mailbox system connectors with no cables attached

Connector

J19

5-bin mailbox system card

See “5-bin mailbox system card” on page 5-18.

Connector Connects to

J1A HTU connector

J1B HTU connector

J2 Motor

J3–Bin1 Output bin 1 sensor

J4–Bin4 Solenoid 4

J5–Bottom Input sensor

J6–Bin2 Output bin 2 sensor

J7–Bin3 Solenoid 3

J8–Bin3 Output bin 3 sensor

J9–Bin2 Solenoid 2

J10–Bin4 Output bin 4 sensor

J11–Top Pass thru sensor

J12–Bin1 Solenoid 1

J13–Bin5 Output bin 5 sensor

J17–LED Output bin LEDs

J18–Program HTU connector

J21–Beacon Jam beacon
