Lexmark C792 series - Page 621

Parts catalog 7-5
5062
Go Back
Previous
Next
Assembly 2: Left and rear covers
Index P/N
Units/
mach
Units/
FRU
Description Removal procedure
2—1 40X7151 1 1 MPF sensor plate assembly “MPF sensor plate assembly
removal” on page 4-108
2 40X7122 1 1 Left cover assembly with LVPS power
switch cable
“Left cover removal” on page 4-11
3 40X7178 1 1 MPF pick tire roll assembly, including
• Pick rolls (x2)
• MPF special wear strip, pellathane
strip
“MPF pick rolls and special wear
strip removal” on page 4-104
4 40X7148 1 1 MPF paper pick assembly, including
• Thrust washer
• Pick tire rolls
“MPF paper pick assembly removal
(including the MPF ratchet collar
and MPF drive pulley)” on
page 4-101
5 40X7156 1 1 Duplex assembly “Duplex assembly removal” on
page 4-53
6 40X7123 1 1 Left access door assembly, including
• Duplex belt shield
• Connector shield
“Left access door assembly
removal” on page 4-5
7 40X7147 1 1 MPF door assembly, including
• MPF door cover
• MPF outer plate
• MPF side restraint
• Paper guide slide
“Multipurpose feeder (MPF) cover
removal” on page 4-17
8 40X7121 Lower left cover “Lower left cover removal” on
page 4-11
9 40X7157 1 1 Belts parts packet, including
• MPF drive belt
• Duplex drive belt
“MPF drive assembly removal” on
page 4-106
“Duplex assembly removal” on
page 4-53
10 40X7150 1 1 MPF pick parts packet, including
• MPF wear strip (x3)
• MPF pulley
• Ratchet collar
“MPF wear strips removal” on
page 4-109
“MPF paper pick assembly removal
(including the MPF ratchet collar
and MPF drive pulley)” on
page 4-101
11 40X7174 1 1 Pins and pads parts packet, including
• Pad (x6)
• Side door front pin
• Side door rear pin
“Pad removal” on page 4-116
“Left access door assembly
removal” on page 4-5
12 40X7138 1 1 System board shield door “System board shield door removal”
on page 4-27
13 40X7106 1 1 Rear upper cover “Rear upper cover removal” on
page 4-22
14 40X7105 1 1 Rear cover “Rear cover removal” on page 4-20
