Lexmark C792 series - Page 631

Parts catalog 7-15
5062
Go Back
Previous
Next
Assembly 5: Rear
Index P/N
Units/
mach
Units/
FRU
Description Removal procedure
5—1 40X0269 1 1 Bolivia, Peru (8’ ST) N/A
40X0270 1 1 Japan (8’ ST)
40X0271 1 1 UK, Ireland (8' ST)
40X0273 1 1 Chile, Uruguay (8’ ST)
40X0275 1 1 Israel (8’ ST)
40X0288 1 1 Argentina (8’ ST)
40X0301 1 1 Australia (8’ ST)
40X0303 1 1 PRC (8’ ST)
40X1772 1 1 Switzerland (8’ ST)
40X1773 1 1 South Africa (8’ ST)
40X1774 1 1 Denmark (8’ ST)
40X1791 1 1 Taiwan (2.5 m ST)
40X1792 1 1 Korea (2.5 m ST)
40X3141 1 1 Europe (8’ ST)
40X4596 1 1 Brazil (8’ ST)
40X7104 1 1 U.S., Canada (8’ ST)
2 40X7131 1 1 Main fan “Main fan removal” on page 4-92
3 40X7128 1 1 LVPS exit duct “LVPS exit duct removal” on
page 4-89
4 40X7129 1 1 LVPS fan “LVPS fan removal” on page 4-90
5 40X7152 1 1 MPF drive assembly “MPF drive assembly removal” on
page 4-106
6 40X7135 1 1 Fuser drive assembly, including
• Gear thrust washer
• Gear–Fuser Dr Compound
“Fuser drive assembly removal” on
page 4-65
7 40X7162 1 1 Waste toner gears parts packet,
including
• Gear–30T Helical
• Gear–46T Spur 17T Helical
“Waste toner gears removal” on
page 4-158
8 40X7137 1 1 Low-voltage power supply (LVPS) with
thermistor retainer
“Low-voltage power supply (LVPS)
removal” on page 4-86
9 40X7140 System board and HVPS card parts
packet, including
• Connector shield (RIP card shield)
• HVPS standoff
• HVPS card standoff
Connector shield—step 3 of “Low-
voltage power supply (LVPS)
removal” on page 4-86
HVPS parts—“High-voltage power
supply (HVPS) board removal” on
page 4-71
10 40X6501 1 1 CPU cooling fan “CPU cooling fan removal” on
page 4-49
11 40X7136 1 1 System board “System board removal” on
page 4-151
12 40X7155 1 1 Exit cooling duct assembly “Exit cooling duct removal” on
page 4-60
13 40X7144 1 1 EP drive assembly “EP drive assembly removal” on
page 4-56
