Lexmark C792 series

To Next Page

To Previous Page

Parts catalog 7-19

5062

Go Back

Assembly 7: Optional 550-sheet drawer assembly

Index P/N

Units/

opt

Units/

FRU

Description Removal procedure

7—1 40X6100 1 1 550-sheet tray controller card

assembly

“550-sheet tray controller card

assembly removal” on page 4-167

2 40X6101 2 2 Anti-tip latch assembly “550-sheet tray right anti-tip latch

assembly removal” on page 4-182

and “550-sheet tray left anti-tip latch

removal” on page 4-173

3 40X6274 1 3 550-sheet/2000-sheet input option

sensor pack

“550-sheet tray pass thru sensor

removal” on page 4-175

4 40X6103 1 1 550-sheet tray pick assembly “550-sheet tray pick assembly

removal” on page 4-176

5 40X6104 2 2 Pick roll assembly “550-sheet tray pick roll assembly

removal” on page 4-180
