Assembly 14: 5-bin mailbox assembly (covers)
Index P/N
Units/
mach
Units/
FRU
Description Removal procedure
14—1 40X7272 1 1 Top cover “5-bin mailbox top cover removal”
on page 4-253
2 40X7266 1 1 Output bin paper bail “5-bin mailbox output bin paper
bail removal” on page 4-247
3 40X7267 1 1 Output bin extension cover “5-bin mailbox tray extension
removal” on page 4-254
4 40X7257 1 1 Output bin light pipe “5-bin mailbox bin-full beacon card
and light pipe removal” on
page 4-237
5 40X7256 1 1 LED card assembly “5-bin mailbox bin-full beacon card
and light pipe removal” on
page 4-237
6 40X7255 1 1 Front cover “5-bin mailbox front cover
removal” on page 4-242
7 40X7261 1 1 LED jam cover “5-bin mailbox access door
removal” on page 4-234
8 40X4528 1 1 Scanner reference LED cable
assembly
“5-bin mailbox paper jam beacon
removal” on page 4-249
9 40X7236 1 1 Beacon clear lens “5-bin mailbox paper jam beacon
removal” on page 4-249
10 40X7259 1 1 Jam access door assembly “5-bin mailbox access door
removal” on page 4-234
11 40X7270 1 1 Rear cover “5-bin mailbox rear cover removal”
on page 4-249
