Lexmark C792 series - Page 653

Parts catalog 7-37
5062
Go Back
Previous
Next
Assembly 15: 5-bin mailbox assembly (interior)
Index P/N
Units/
mach
Units/
FRU
Description Removal procedure
15—1 40X7263 1 1 Top output bin roller “5-bin mailbox roller removal” on
page 4-251
2 40X7264 1 1 1 thru 4 output bin roller “5-bin mailbox roller removal” on
page 4-251
3 40X5545 4 1 Output bin LED “5-bin mailbox cave beacon
removal” on page 4-237
4 40X5727 1 1 LED clear lens “5-bin mailbox cave beacon
removal” on page 4-237
5 40X4647 1 1 Output bin LED bracket “5-bin mailbox cave beacon
removal” on page 4-237
6 40X7265 1 1 Pass thru sensor “5-bin mailbox sensor (pass thru)
assembly removal” on page 4-252
7 40X4633 1 1 Bin full sensor “5-bin mailbox output bin sensors
removal” on page 4-248
8 40X7268 1 1 Bin full flag “5-bin mailbox media bin full
actuator removal” on page 4-244
9 40X4635 4 1 Deflector gate solenoid “5-bin mailbox diverter solenoid
removal” on page 4-239
10 40X5750 4 1 Diverter spring “5-bin mailbox diverter spring
removal” on page 4-240
11 40X7262 5 1 Output bin deflector “5-bin mailbox output bin deflector
removal” on page 4-246
12 40X7260 1 1 Backup roll plate “5-bin mailbox backup roll plate
assembly removal” on page 4-235
13 40X7269 1 1 Feed motor with bracket “5-bin mailbox feed motor with
plate removal” on page 4-241
14 40X7271 1 1 Controller card “5-bin mailbox controller card
removal” on page 4-238
