Parts catalog 7-41
5062
Assembly 17: HTU (covers)
Index P/N
Units/
mach
Units/
FRU
Description Removal procedure
17—1 40X7287 1 1 HTU top right cover “HTU top right cover removal” on
page 4-329
2 40X4528 1 1 HTU access door beacon card “HTU access door paper jam
beacon (with cover and cable)
removal” on page 4-283
3 40X5544 1 1 Receive PCBA (transparency detect) “HTU access door paper jam
beacon (with cover and cable)
removal” on page 4-283
4 40X5544 2 1 Receive PCBA (bin full) “HTU card (bin-full send card and
lens) removal” on page 4-288
5 40X7285 1 1 HTU right bottom cover “HTU right bottom cover removal”
on page 4-315
6 40X7280 1 1 HTU front standard bin cover “HTU front standard bin cover
removal” on page 4-294
7 40X7274 1 1 HTU outer front cover (AIO only) “HTU outer front cover removal
(AIO only)” on page 4-310
8 40X7279 1 1 HTU front redrive cover “HTU front redrive cover removal”
on page 4-293
9 40X7286 1 1 HTU top redrive cover “HTU top redrive cover removal”
on page 4-328
10 40X7277 5 2 HTU access door rollers “HTU access door rollers removal”
on page 4-284
11 40X7258 1 1 HTU rear redrive cover “HTU rear redrive cover removal”
on page 4-310
12 40X7283 1 1 HTU rear standard bin cover “HTU rear standard bin cover
removal” on page 4-312
13 40X7276 1 1 HTU access door “HTU access door removal” on
page 4-282
