Lexmark C792 series User Manual

Parts catalog 7-43
5062
Go Back
Previous
Next
Assembly 18: HTU (left interior)
Index P/N
Units/
mach
Units/
FRU
Description Removal procedure
18—1 40X7305 1 1 HTU upper redrive guide “HTU upper guide removal” on
page 4-332
2 40X7312 1 1 HTU lower redrive guide “HTU lower redrive guide removal”
on page 4-297
3 40X7314 3 1 HTU input sensor
HTU 2nd sensor
HTU output sensor
“HTU sensor (input) removal” on
page 4-322
“HTU sensor (second) removal” on
page 4-324
“HTU output sensor removal” on
page 4-309
4 40X7324 1 1 Drive motor gears parts pkt
• M6 e-clip
• 4 mm e-clip
• Redrive pulley
• Pulley gear
• Idler roller
“HTU transport gear removal” on
page 4-330
5 40X7288 1 1 HTU belts/pulley parts pkt “HTU drive belt removal” on
page 4-290 and “HTU timing belts
(rear) removal” on page 4-326
6 40X4626 1 1 HTU bin full send card “HTU card (bin-full send card and
lens) removal” on page 4-288
7 40X7315 2 1 HTU bin full send/rec lens “HTU card (bin-full receive card
and lens) removal” on page 4-287
8 40X7302 1 1 HTU controller card “HTU controller card removal” on
page 4-289
9 40X7316 1 1 HTU drive gear spring “HTU drive gear spring removal”
on page 4-291
