Lexmark C792 series User Manual

Parts catalog 7-45
5062
Go Back
Previous
Next
Assembly 19: HTU (right interior)
Index P/N
Units/
mach
Units/
FRU
Description Removal procedure
19—1 40X7304 2 1 HTU output option with spring hook
• Spring torsion hook front
“HTU option hook removal” on
page 4-300
2 40X7303 4 2 HTU (engage/output option) roller “HTU engagement roller removal”
on page 4-292 and
“HTU option roller removal” on
page 4-302
3 40X7319 1 1 HTU upper exit shaft “HTU upper exit shaft removal” on
page 4-331
4 40X7318 1 1 HTU exit roller “HTU exit roller removal” on
page 4-293
5 40X4618 1 1 HTU empty bin sensor “HTU sensor (empty bin) removal”
on page 4-321
6 40X7307 1 1 HTU output bin “HTU output bin removal” on
page 4-303
7 40X7306 1 1 HTU output bin extension “HTU output bin extension
removal” on page 4-303
8 40X7308 1 1 HTU output bin stop “HTU output bin wire stop
removal” on page 4-305
9 40X7315 2 1 HTU bin full send/receive lens “HTU card (bin-full receive card
and lens) removal” on page 4-287
10 40X5544 1 1 HTU bin full receive PCBA “HTU card (bin-full receive card
and lens) removal” on page 4-287
11 40X7310 1 1 HTU output bin divert solenoid “HTU output bin solenoid removal”
on page 4-304
12 40X7281 1 1 HTU locking lever “HTU locking lever removal” on
page 4-295
13 40X7311 1 1 HTU stop diverter “HTU stopper diverter removal” on
page 4-325
14 40X7309 1 1 HTU output option diverter solenoid “HTU output option solenoid
removal” on page 4-308
15 40X7282 1 1 HTU locking lever PCBA “HTU locking lever card removal”
on page 4-297
16 40X7300 2 1 HTU diverter gate spring “HTU bin diverter gate spring
removal” on page 4-286 and
“HTU bin media exit spring
removal” on page 4-286
17 40X7313 2 1 HTU access door sensor
HTU output option position sensor
“HTU sensor (access door
interlock) removal” on page 4-320
“HTU sensor (output option
position) removal” on page 4-323
18 40X7278 1 1 HTU sensor housing “HTU sensor (access door
interlock) removal” on page 4-320
19 40X7317 1 1 HTU transport motor “HTU transport motor removal” on
page 4-331
20 40X7284 1 1 HTU output option guide “HTU output option guide removal”
on page 4-308
