Configuring ATM Logical Ports on Frame-based Modules
About ATM Logical Port Functions
ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000 1/19/054-11
About ATM Logical Port Functions
Chapter 3 contains instructions for accessing the Add Logical Port dialog box and
provides an overview of the tabs and fields contained in this dialog box.
• To access the Add Logical Port dialog box, complete the steps in “Working With
ATM Logical Ports” on page 3-2.
• To review information about this dialog box, see “Defining a Logical Port” on
page 3-9.
About the ATM Logical Port Attributes
When you define a new logical port, the Add Logical Port dialog box contains several
tabs containing a variety of parameters that you must specify. Table 4-4 describes the
options you can configure for each ATM logical port type. Keep in mind that some
options are only available for certain card types and the attributes available on any tab
may vary, depending on the type of service and card type.
Table 4-4. Add Logical Port Tabs
Tab Name Description Logical Port
Type
Card Types
General Sets the Admin status, connection
ID, resource partitioning, and net
overflow.
All All
Administrative Specifies the number of channels
allocated to each port, committed
information rate (CIR)
parameters, shaping type, and
path trace parameters.
All All
ATM Sets the ATM parameters, which
include the number of valid bits
in the VPI/VCI, the ATM
protocol, and the UNI type.
UNI DCE/DTE
ATM CS
and IWU
cards
