Beta Draft Confidential
9-201/19/05 ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000
Configuring ATM Over MPLS Gateway Solution on CBX 3500
Configuring a Layer 2 Tunnel Over MPLS Core Network
Figure 9-9. Add Logical Port Dialog Box: Point-to-Point
7. Complete the fields in the tabs in the Add Logical Port dialog box as described in
Table 9-6.
Table 9-6. Add Logical Port Dialog Box Tabs
Tab See...
General “General Attributes for POS LPorts” on
page 9-21
Administrative “Administrative Attributes for POS LPorts” on
page 9-22
QoS “QoS Attributes for POS LPorts” on page 9-23
Trap Control “Trap Control Attributes” on page 9-26
MPLS “MPLS Attributes for POS LPorts” on
page 9-28
Congestion Control “Congestion Control Attributes” on page 9-30
Point-to-Point “Point to Point Attributes” on page 9-31
