D-101/19/05 ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000
ATM FCP Rate Profile Tables
MCR Class Mappings
OC-3/STM-1 IOM MCR Class Mapping
Table D-4 shows the MCR ranges and MCR classes for OC-3/STM-1 IOMs.
Table D-4. OC-3/STM-1 IOM MCR Class Mapping
MCR Range MCR Class MCR Range MCR Class MCR Range MCR Class
100 - 255 1 3200 - 3327 25 6272 - 6399 49
256 - 383 2 3328 - 3455 26 6400 - 6527 50
384 - 511 3 3456 - 3583 27 6528 - 6655 51
512 - 639 4 3584 - 3711 28 6656 - 6783 52
640 - 767 5 3712 - 3839 29 6784 - 6911 53
768 - 895 6 3840 - 3967 30 6912 - 7039 54
896 - 1023 7 3968 - 4095 31 7040 - 7167 55
1024 - 1151 8 4096 - 4223 32 7168 - 7295 56
1152 - 1279 9 4224 - 4351 33 7296 - 7423 57
1280 - 1407 10 4352 - 4479 34 7424 - 7551 58
1408 - 1535 11 4480 - 4607 35 7552 - 7679 59
1536 - 1663 12 4608 - 4735 36 7680 - 7807 60
1664 - 1791 13 4736 - 4863 37 7808 - 7935 61
1792 - 1919 14 4864 - 4991 38 7936 - 8063 62
1920 - 2047 15 4992 - 5119 39 8064 - 8191 63
2048 - 2175 16 5120 - 5247 40 8192 - 8447 64
2176 - 2303 17 5248 - 5375 41 8448 - 8703 65
2304 - 2431 18 5376 - 5503 42 8704 - 8959 66
2432 - 2559 19 5504 - 5631 43 8960 - 9215 67
2560 - 2687 20 5632 - 5759 44 9216 - 9471 68
2688 - 2815 21 5760 - 5887 45 9472 - 9727 69
2816 - 2943 22 5888 - 6015 46 9728 - 9983 70
2944 - 3071 23 6016 - 6143 47 9984 - 10239 71
3072 - 3199 24 6144 - 6271 48 10240 - 10495 72
