Configuring ATM PVCs
Defining a Point-to-Point Circuit Connection
ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000 1/19/0510-13
Defining a Point-to-Point Circuit Connection
To set up a PVC connection between two UNI or NNI logical ports:
1. In the Switch tab, expand the Circuits node.
2. Right-click on the PVCs node and select Add on the popup menu, as shown in
Figure 10-1.
The Add PVC dialog box (Figure 10-3) appears.
Figure 10-3. Add PVC Dialog Box
3. Choose the Select button in the Endpoints field to define the circuit endpoints.
The Select Endpoints dialog box (Figure 10-4) appears.
