Configuring ATM Over MPLS Gateway Solution on CBX 3500
Network-wide MPLS Settings
ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000 1/19/059-9
3. Complete the fields as described in Table 9-2.
Table 9-2. Add Hoplist Dialog Box Fields
Field Description
Name Enter a unique alpha-numeric name for this hoplist.
Unassigned
Switches
Select from the list of available switches to add to the hoplist.
Multiple switches can be selected by holding the Ctrl key while
clicking on the switch names.
Assigned Switches A list of switches that have been assigned to the tunnel hoplist
to create a list of hops that must be part of the route used.
To add to this list, select a switch from the Unassigned Switches
list and click the right arrow button.
To remove a switch from this list, select the switch in the
Assigned Switches list and click the left arrow button.
To reorder the switches in this list, highlight the switch and
click the up or down arrow button to move it up or down the list.
For each switch defined in this list, the following fields are
available:
Name – displays the name of the switch.
Type – displays the switch type, for instance, CBX 3500.
LsrID – displays the LSR ID of the switch.
Include/Exclude – Displays whether the switch is included or
excluded from the hop list.
Strict/Loose – If an explicit route is strict, the tunnel must
include the specified hop. If an explicit route is loose, the
specified hop should be included, if possible, but the path is
otherwise unrestricted.
Prefix – Accept the default of 32.
Non-Lucent IP To add a non-Lucent switch to the hoplist, enter the IP address,
then click the up arrow to the right of this field. The IP address
will be entered in the LSR ID column in the Assigned Switches
list and the switch will be included in the hop list.
