Configuring SVC Parameters
Configuring SVC Attributes
ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000 1/19/0517-11
Signaling Attributes for SVCs
The Signaling tab allows you to configure the SVC proxy signaling agent (PSA),
VPCI/VPI mapping, proxy signaling client (PSC), and the tuning parameters. To
configure the signaling attributes:
1. From the Configure SVC dialog box, select the Signaling tab (Figure 17-5).
Figure 17-5. Configure SVC: Signaling Tab
Complete the fields in the Signaling tab as described in Table 17-3.
Table 17-3. Configure SVC: Signaling Tab Fields
Field Description
Enable Signaling Select the check box to enable SVC proxy signaling.
Signaling Channel Traffic Descriptors
Override Default (for
Forward signaling)
Select the check box to override the default TD for
forward signaling. You can then select a different TD.
Clear the check box to use the default TD for forward
signaling. You will not be able to select a different TD.
Forward PMP Rev, Unsp
CBR
Choose a TD for forward signaling. This field is
enabled only if you selected the Override Default check
box (for forward signaling).
