Configuring Management Paths
Using MPVCs
10. Enter the VPI/VCI or DLCI values as follows:
• For an ATM UNI endpoint, enter a VPI and VCI value. See “About the PVC
Tabs” on page 10-16 for instructions.
• For a Frame Relay UNI endpoint, enter a DLCI value. See page 10-67 for a
description of this field.
11. Enter a Circuit Name for the MPVC. You will select this name when you
configure the NMS path.
12. Set the remaining PVC attributes as shown in Table 11-1.
13. (Optional) To configure CBX 500 or GX 550 Network Data Collection (NDC)
parameters for this circuit, select the NDC tab. For more information, see the
Switch Diagnostics User’s Guide
for CBX 3500, CBX 500, GX 550, and B-STDX 9000.
14. (Optional) To configure NavisXtend Accounting Server parameters for this
circuit, select the Accounting tab. For more information, see the NavisXtend
Accounting Server Administrator’s Guide.
15. Choose OK to define the circuit parameters.
16. Continue with “Completing the Management Configuration” on page 11-15 to
define the NMS path and static route.
Table 11-1. Configuring Standard MPVC Attributes
For an ATM Service PVC see... For an Interworking PVC see...
Table 10-3 on page 10-17 to set the
Administrative Attributes
Table 10-11 on page 10-49 to set the
Administrative Attributes
Table 10-4 on page 10-23 to set the
Traffic Type Attributes
Table 10-12 on page 10-55 to set the
Traffic Type Attributes
Table 10-5 on page 10-27 to set the
User Preference Attributes
Table 10-13 on page 10-61 to set the
User Preference Attributes
Table 10-6 on page 10-32 to set the
Traffic Mgmt. Attributes
“Manually Defining the Circuit Path”
on page 10-68 to set the Path Attributes
“Manually Defining the Circuit Path” on
page 10-68 to set the Path Attributes
