Configuring Management Paths
Completing the Management Configuration
ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000 1/19/0511-15
Completing the Management Configuration
To complete the management configuration, you must define the NMS path and
configure the attached device.
Defining the NMS Path
To define an NMS path:
1. Expand the Switches class node for the switch you want to add NMS paths to.
2. Expand the instance node for the switch you want to add NMS paths to.
3. Right-click on the NMS Paths node and select Add from the pop-up menu.
The Add NMS path dialog box appears.
Figure 11-6. Add NMS path Dialog Box
4. Complete the steps in one of the following three sections, then continue with
step 5 on page 11-16.
For Standard or Redirect MPVCs
a. Enter the Management IP Address. This is the NMS IP address of the
SPARCstation to which this switch connects.
b. Select Management PVC from the pull-down list in the Access Path field.
c. Choose the Select button to select the Management PVC Name you entered in
step 11 on page 11-6 for a standard MPVC (or in step 7 on page 11-7 for a
redirect MPVC).
