Beta Draft Confidential
Configuring SVC Parameters
Configuring SVC Port Addresses
ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000 1/19/0517-57
The steps in the following sections present both the manual method and the automatic
assignment method of populating the ESI bytes. There may be certain situations where
one method is favored over the other.
To configure SVC port addresses:
1. Expand the instance node for the LPort for which you want to add an SVC port
address.
2. Expand the SVC class node under the LPort instance node. The Port Addresses
class node appears under the SVC class node.
3. Right-click on the Port Addresses class node and select Add from the pop-up
menu. The Add SVC Port Address dialog box appears (Figure 17-28).
.
Figure 17-28. Add SVC Port Address Dialog Box
4. Select an address format and scope. See page 17-32 for a description of these
address formats.
Note – The Node Prefix must be configured on the switch for the Use Auto ESI
Assignment field on the Add SVC Port Address dialog box to be available.
