Beta Draft Confidential
19-81/19/05 ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000
CUGs
Administrative Tasks
The Add CUG Member dialog box appears (Figure 19-3).
Figure 19-3. Add CUG Member Dialog Box
4. Complete the fields in the Add CUG Member dialog box as described in
Table 19-4.
5. When you finish, choose Apply to commit the configuration and configure
additional CUG members; or choose OK to add the CUG member and return to
the Navis EMS-CBGX window.
Table 19-4. Add SVC CUG Member Dialog Box
Field Description
CUG Member Name Enter a name (up to 32 characters).
CUG Member Value Enter the CUG member rule using the guidelines in “About
CUG Member Rules” on page 19-2. Do not enter more than 15
characters for an E.164 address or more than 14 characters for
an X.121 address.
Type Select X.121, E.164, or AESA.
Access: Incoming
(IA)
This attribute specifies how incoming calls from non-CUG
users or users of a different CUG are handled.
Select the check box to accept calls from users that do not
belong to the same CUG.
Clear the check box (default) to reject calls from users that do
not belong to the same CUG.
Access: Outgoing
(OA)
This attribute specifies how outgoing calls to non-CUG users
or users of a different CUG are handled.
Select the check box to allow calls to users not belonging to the
same CUG.
Clear the check box (default) to block calls to users not
belonging to the same CUG.
To Next Page
