Configuring SPVCs
Defining a Point-to-Point Offnet Circuit Connection
Table 18-4. Add OffNet Circuits: Administrative Tab Fields
Field Action/Description
Circuit Name Enter any unique, alphanumeric name to identify the Offnet circuit. Do
not use parentheses and asterisks.
Circuit Alias
Name
(Optional) The circuit alias is used by service providers to identify the
circuit in a way that is meaningful to their customers. This option is
often used in conjunction with NavisXtend Report Generator.
Enter any unique, alphanumeric name to identify the Offnet circuit. Do
not use parentheses and asterisks. This name must be unique to the entire
map.
Admin Status Up – Choose this button (default) to activate the circuit at switch startup.
Down – Choose this button if you do not want to activate the circuit at
switch startup.
Circuit Type
(ATM-to-ATM
only)
Specify whether the circuit is a VPC or VCC (default).
VPC – Choose this button for the VCI field to be set to zero (0). It cannot
be changed. A VPC enables a network that interfaces with an OPTimum
trunk to accept circuits with this VPI and any of its valid VCIs.
VCC – Choose this button to accept the default of this circuit being a
VCC.
Endpoint 1
Connection ID
VPI (0-15) – For ATM UNI endpoints only, enter a value from 0 – nnnn
to represent the VPI for the Offnet PVC. The maximum value you can
enter is based on the Valid Bits in VPI that is configured for the logical
port. Note that zero (0) is not a valid value for a management PVC.
VCI (32-1023) – For ATM UNI endpoints only, enter a value to represent
the VCI for the Offnet PVC.
DLCI – (Frame Relay UNI endpoints only) If applicable, displays the
data link connection identifier (DLCI), a 10-bit address that identifies
PVCs. The DLCIs identify the logical end points of a virtual circuit and
only have local significance.
