Beta Draft Confidential
18-221/19/05 ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000
Configuring SPVCs
Defining a Point-to-Point Offnet Circuit Connection
Accounting Attributes
1. Select the Accounting tab from the Add OffNet Circuit dialog box (Figure 18-7)
to set the accounting parameters for this offnet circuit.
Figure 18-7. Add OffNet Circuit: Accounting Tab
2. Complete the Accounting tab fields, as described in Table 18-7.
Table 18-7. Add OffNet Circuit: Accounting Tab Fields
Field Action/Description
Carrier ID (Endpoint 1) Displays the 5-digit Carrier identifier (ID). This number
uniquely identifies the carrier at each end of the network
interface. If you have not yet configured accounting at the
LPort level, then this field is set to zero (0).
Recording Interface ID
(Endpoint 1)
Displays the 16-digit circuit Recording Interface ID, made up
of the 12-digit IP address and the LPort interface number (no
dots, and padded with zeros to fill all 12 digits).
Chargeable Party ID If applicable, enter the chargeable party ID (in decimal format)
for the circuit.
