Configuring ATM Over MPLS Gateway Solution on CBX 3500
Configuring a Layer 2 Tunnel Over MPLS Core Network
ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000 1/19/059-31
Point to Point Attributes
Select the Point to Point tab (Figure 9-15) and complete the fields as described in
Table 9-12.
Figure 9-15. Add Logical Port: Point to Point Tab
Table 9-12. Add/Modify Logical Port: Point to Point Tab
Element Description
Echo Request Send
To Remote User
Select On to send keep-alive packets to the remote user.
Maximum Tries
(1-99)
Enter a number from 1 to 99 that represents the maximum
number of keep-alive packets sent to the remote user.
Interval (1-99) Enter a number from 1 to 99 that represents the time interval
between each keep-alive packet.
Maximum LCP
Negotiation Time
The maximum time interval for the Link Control Protocol
(LCP) to negotiate the exchange of packets.
