Beta Draft Confidential
4-14 ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000
Configuring ATM Logical Ports on Frame-based Modules
Adding an ATM Logical Port
Adding an ATM Logical Port
Adding an logical port on a frame-based module is similar to adding a logical port on
an ATM-based module.
To add an ATM logical port:
1. Follow the steps step 1 through step 5 in “Adding an ATM Logical Port” on
page 3-4 to access the switch object tree and the Add Logical Port dialog box.
2. In the LPort Type field, select the ATM logical port type you want to configure
from the pull-down list.
The available options in the LPort Type field differ depending on the supported
ATM logical port types for your module. Possible options include:
•ATM UNI DCE
•ATM UNI DTE
• ATM Direct Line Trunk
• ATM OPTimum Cell Trunk
• ATM Direct Frame Trunk
• ATM Network Interworking for FR NNI
See Table 4-5 to continue this configuration.
Table 4-5. Configuring ATM Logical Port Types
Logical Port Type See...
ATM UNI DTE or
ATM UNI DCE
“Defining ATM UNI DCE/DTE Logical Ports” on page 4-15.
ATM OPTimum Cell
Trunk or
ATM Direct Trunk
“Defining ATM Direct Trunk and OPTimum Cell Trunk
Logical Ports” on page 4-36.
ATM OPTimum
Frame Trunks
“Defining ATM OPTimum Frame Trunk Logical Ports” on
page 4-40.
ATM Network
Interworking for FR
NNI
“Defining ATM Network Interworking for Frame Relay NNI
Logical Ports” on page 4-42.
