Beta Draft Confidential
17-441/19/05 ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000
Configuring SVC Parameters
Configuring SVC Port Prefixes
DCC and ICD AESA Port Prefix Format
Complete the following fields for the DCC or ICD AESA port prefix format
(Figure 17-21):
Figure 17-21. Add SVC Port Prefix: DCC and ICD
AESA Format
1. In the DCC field, enter the DCC of the country in which the address is registered,
or the ICD that identifies the international organization to which this address
applies. DCCs and ICDs consist of 4 hex digits, and occupy two octets.
2. (Optional) Enter the HO-DSP, ESI, and SEL portions of the address.
For information on the appropriate format to use for DCC and ICD addresses, see
“AESA Formats” on page 16-2.
3. As you enter the address, the value in the Bit Length field changes to indicate the
number of address bits that are checked during call screening and call routing.
(The value increases by eight with each pair of address digits you type.) Click on
one of the numbered radio buttons to decrease the number of address bits that are
checked, thereby enabling the node to perform call screening and call routing
down to the bit level. You can decrease the value by 1-7 bits.
Note – To register the AESA address in the attached DTE devices’ ILMI prefix table,
enter exactly the first 13 octets (26 digits) of the AESA address. Address registration
occurs only on ILMI-enabled UNI ports.
