Beta Draft Confidential
Configuring SVC Parameters
Configuring SVC Port Addresses
ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000 1/19/0517-65
Configuring PVP and PVC Termination
1. Select the Termination tab in the Modify SVC Port Address dialog box
(Figure 17-35).
Figure 17-35. Modify SVC Port Address: Termination Tab
2. Complete the fields in the Termination tab as described in Table 17-15.
Table 17-15. Add SVC Port Address: Termination Tab Fields
Field Action/Description
PVP Select this check box if you want to terminate an SPVC to this
address on the logical port.
Any Connection ID – Choose this button if you want the network to
allocate a VPI for the soft permanent virtual path connection
(SPVPC). Note that if you selected the check box in the PVC field,
this button is automatically chosen and cannot be changed.
Specify Connection ID – Choose this button if you want to supply a
VPI. Note that if you place a check in the PVC box, this button
cannot be chosen. Any Connection ID is automatically chosen
instead.
VPI (1-15) – Enter the VPI of the logical port on which you want the
switch to terminate this SPVPC. The logical port cell header type
limits the range of values you can enter: UNI = 255, NNI = 4095.
