Beta Draft Confidential
10-861/19/05 ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000
Configuring ATM PVCs
Configuring PMP Circuits
5. Choose Apply to configure the PMP PVC leaf parameters.
6. To define additional PMP circuits and endpoints, repeat step 1 through step 5.
When you are done adding PMP circuits and endpoints, choose OK to return to
the network map.
Restrictions on Multiple Leafs on the Same Physical Port
Logical multicasting is not supported on the GX 550 switch. In this situation, you
should not configure more than one PMP leaf on a physical port. Do not configure
more than one circuit leaf for a given root on the same physical port. If you configure
more than one OPTimum trunk on a physical port, only one OPTimum trunk can be
used for routing one of the leafs for a given root.
Ingress Cell Counting, Egress
Cell Counting
Select the check box for Ingress and Egress Cell
Counting to include cell counts from this circuit
in PVC usage data collection, when PVC
Accounting is set to Enabled at the switch and
port levels. If you select either or both cell
counting fields, the resulting accounting records
contain both time-based and usage-based
measurements.
If you clear the check box for Ingress or Egress
Cell Counting, cell counts from this circuit are
not included in PVC usage data collection. If
you do not select either cell counting field, the
resulting usage data records contain only
time-based measurements.
PVC Accounting Enable — PVC usage data is collected on the
PVC, if PVC Accounting is set to Enabled at
the switch level.
If PVC Accounting is set to Disabled at the
switch level, setting this field to Enabled has no
effect (accounting will still be inhibited on the
PVC).
Disable — PVC usage data is not collected on
the PVC, even if PVC Accounting is set to
Enabled at the switch level.
Study — Functions the same as the Enabled
setting, except that the resulting records are
marked as “study” to differentiate them from
normal accounting records. This feature enables
you to collect information for research.
Table 10-18. Add Point-to-Multipoint PVC Leaf: Accounting
Tab Fields (Continued)
Field Action/Description
