Beta Draft Confidential
8-341/19/05 ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000
Configuring ATM Over MPLS Trunks
Configuring ATMoMPLS Trunk Logical Ports
Configuring ATMoMPLS Trunk Logical Ports
After the feeder logical port has been configured, you can define an ATMoMPLS
Trunk logical port.
To configure an ATMoMPLS trunk logical port using Navis EMS-CBGX:
1. Expand the node for the PPort or subport to which you want to add an LPort.
The LPorts node appears under the PPort or subport node.
Figure 8-17. Managing LPorts
2. Right-click on the LPorts node and select Add from the pop-up menu (see
Figure 8-17).
The Add Logical Port dialog box appears (Figure 8-18).
Figure 8-18. Add Logical Port Dialog Box
