Setting Logical Port FCP Attributes
ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000 1/19/056-11
Beta Draft Confidential
Figure 6-4. Add Logical Port: ATM FCP Tab (1-Port Channelized
STM/E1 ATM w/IMA Enhanced IOM)
3. Complete the fields as described in Table 6-2.
Table 6-2. Add Logical Port: ATM FCP Tab Fields
Field/Button Description
Auto RM Generation Select the mode for Auto RM Generation. Options include:
Allow (default) – RM cell generation is automatically
disabled for a VC if no upstream FCP-enabled IOM is
detected for the VC in the adjacent upstream switch.
Override – The switch continues to generate RM cells
regardless of whether or not an adjacent upstream switch
contains an FCP-enabled IOM.
Cell Generation Select the type of cell to generate for the VC. Options
include:
No Loop (default) – VC will generate no RM cells.
CCRM – VC will generate CCRM cells.
BCM – VC will generate BCM cells.
