Beta Draft Confidential
Configuring SPVCs
Defining a PMP SPVC (Offnet Circuit)
ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000 1/19/0518-39
Selecting an Endpoint From a Switch
To select an endpoint from a switch:
1. In the Select Endpoint dialog box, expand the node for the desired switch for the
endpoint.
2. Expand the LPorts node under the switch, and select the desired LPort.
3. Select the Address tab and enter the address prefix in the Prefix field
(Figure 18-18).
Figure 18-18. Select Endpoint: Address Tab
4. Choose OK and continue with “Configuring Offnet PMP Leaf Parameters” on
page 18-40.
Selecting an Endpoint From a Physical Port
To select an endpoint from a physical port:
1. In the Select Endpoint dialog box, expand the node for the desired switch for the
endpoint (Figure 18-17).
2. Expand the Cards node.
3. Expand the node for the desired card.
4. Expand the PPorts node.
