D-21/19/05 ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000
ATM FCP Rate Profile Tables
Determining FCP Rate Profile Values
Determining FCP Rate Profile Values
Perform the following tasks to determine the minimum cell rate (MCR) class, local
discard threshold, local congestion threshold, RIE, and RDE for each virtual circuit
(VC) you configure.
1. Find the MCR class based on the module configuration as explained in “MCR
Class Mappings” on page D-4.
2. Use the MCR class found in step 1 to find the FCP rate profile table values.
Table D-1 shows the default FCP profile values.
Table D-1. FCP Rate Profile Values (by MCR Class)
MCR Class Local Discard
Threshold
(in Cells)
Local Congestion
Threshold
(in Cells)
RIE RDE
032 16 63
1-27 32 16 11 3
28-55 32 16 10 4
56-83 32 16 9 5
84-110 32 16 8 5
111-138 32 16 7 6
139-166 32 16 6 6
167-194 32 16 5 7
195-221 32 16 4 8
222-255 32 16 3 8
