CUGs
Administrative Tasks
ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000 1/19/0519-9
Defining a CUG
Next, set up the CUGs for your network. This is a simple process of supplying a name
for each CUG.
Observe the following configuration limits:
• Up to 1024 CUGs per switch are supported.
• You can assign up to 128 members per CUG.
• You can assign each member to as many as 16 CUGs.
To create a CUG:
1. In the Networks tab, expand the network you are managing.
2. Expand the SVC Security node.
3. Right-click on the CUGs node and click Add on the pop-up menu, as shown in
Figure 19-4.
Figure 19-4. Defining a CUG
The Add CUG dialog box appears (Figure 19-5).
Figure 19-5. Add CUG Dialog Box
