9-121/19/05 ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000
Configuring ATM Over MPLS Gateway Solution on CBX 3500
Network-wide MPLS Settings
7. When you complete the configuration, choose OK to save the changes and close
the dialog box.
Table 9-3. Add IntServ Dialog Box Fields
Field Description
Intserv ID An index for the IntServ profile, automatically generated by
Navis EMS-CBGX.
MaxRate
(0-4294967295Kbps)
Enter the maximum rate of the LSP in units of 1000 bits per
second.
MeanRate
(0-4294967295Kbps)
Enter the mean rate of the LSP in units of 1000 bits per
second.
Max Burst Size
(0-4294967295Kbps)
The maximum burst rate this LSP can forward data without
dropping data, in bytes.
IntServJ
• NetCT0BW
(0-4294967295
Kbps)
• NetCT1BW
(0-4294967295
Kbps)
• NetCT2BW
(0-4294967295
Kbps)
• NetCT3BW
(0-4294967295
Kbps)
Bandwidth allocated per class type (0-3). The value in this
field cannot exceed the maximum bandwidth of the physical
port that the LSP could possibly traverse.
(E-LSP-IntServJ only)
